5000 WATT GENERATOR WINCO (29005-006)
$ 1,999.00
5000 WATT GENERATOR WINCO (29005-006)
5000 WATT GENERATOR WINCO
Description:
FEATURES:
- Honda GX270 Engine – You expect the best, you get the best. The Honda GX270 engine has more power, lower fuel consumption, and lower emissions than previous versions.
- Low Oil Protection – In the event there is a low oil level, the engine will shut down to protect the engine from damage.
- 8 Gallon Fuel Tank – The EPA-approval steel fuel tank design eliminates carbon emissions.
- 100% Load Tested – Every generator is fully tested prior to leaving Winco’s facility.
DP5000/T Engine Specifications:
| ENGINE BRAND | HONDA |
| ENGINE MODEL | GX270 |
| ENGINE STARTER | RECOIL |
| ENGINE SPEED | 3600 RPM |
| ENGINE CYLINDERS | SINGLE |
| DISPLACEMENT/TYPE | 270 CC / OHV |
| FREQUENCY REGULATION | +/- 3% |
| LOW OIL PROTECTION | STANDARD |
| RECOMMENDED OIL | 10W-30 |
| OIL CAPACITY | 1.2 QT |
| FUEL TANK | 8 GAL |
| FUEL GAGE | ON TANK |
| FULL LOAD RUN TIME | 10.6 HOURS |
| FUEL CONSUMPTION | GAL/HR |
| 100% | 0.75 |
| 75% | 0.59 |
| 50% | 0.44 |
| 25% | 0.33 |
| 0% | 0.23 |
| DERATES ABOVE SEA LEVEL EVERY 1,000 FT | 3.5% |
DP5000/T Generator Specifications:
| STARTING WATTS | 5,000 |
| RUNNING WATTS | 4,560 |
| RUNNING AMPS @120 VAC | 38 |
| RUNNING AMPS @240 VAC | 19 |
| VOLTAGE REGULATION | CAPACITOR +/- 5% |
| MAIN CIRCUIT BREAKER | 20 AMP, 240V (GFCI) |
| BONDED NEUTRAL | YES |
| 120 VOLT RECEPTACLES | (2) NEMA 5-20 20A (GFCI) |
| 120/240 VOLT RECEPTACLES | (1) NEMA L14-30 30A (GFCI) |
| YOURGEN METER | STANDARD |
| MOTOR STARTING (CODE G) | 1.5 HP |
| DBA @ 7 METERS | 80.6 |
| TOTAL HARMONIC DISTORTION | <6% |
| LIFTING EYE | STANDARD |
| 2 WHEEL DOLLY KIT | OPTIONAL |
| INSULATION | CLASS H |
| PROTECTIVE ROLL FRAME | 1.25″ DIAMETER 14 GAUGE STEEL |
| ASSEMBLED IN | USA |
| EPA APPROVED | YES |
| CARB APPROVED | YES |
| CSA APPROVED | NO |
| UNIT WARRANTY | 3 YEARS COMMERCIAL |
| SHIPPING DIMENSIONS | 30″ x 22″ x 24″ |
| SHIPPING WEIGHT | 178 LBS |
| FREIGHT CLASS | 70 |
Additional information:
| Weight | 178 lbs |
|---|---|
| Dimensions | 30 × 22 × 24 in |
